EZ Dock
EZ Dock is a lightweight, durable, modular, floating, composite pontoon system that can be formed into a wide variety of custom configurations to perfectly suit your requirements.
The EZ Dock polyethylene constructions offers unbeatable adaptability, exceptional performance in rough water, superior strength and durability, virtually no upkeep, universal accessibility, superb buoyancy, and easy installation.
Combine various size sections and accessories to create simple straight-dock designs and complex configurations featuring multiple ports and platforms.
It is an extremely versatile dock system providing cost-effective mooring solutions for boats, RIBs, Jet Skis, canoes and much more. This dock system can be used in various applications including floating work platforms, float docks, by the military, by hotels and resorts, by fish farms, special entertainment areas, diving platforms and more.
Key Points
- Excellent stability on the water.
- Low maintenance.
- Beige “cool-to-touch” colour.
- Safe, slip-resistant surface.
- Strength and flexibility.
- Convenient dock accessories.
- Versatile modular design and flexibility.
- Expandable for future growth.
- Variety of dock and anchoring options.
- Custom designs available.
- Maintenance-free and barefoot friendly.
- Flexible flotation technology.
- Innovative coupling.
Specifications
| Dock Sections | Size (W x L x H) | Area | Weight | Flotation Capacity | |
|---|---|---|---|---|---|
| 1 | 40” x 5’ Dock | 40 x 60 x 15” / 1m x 1.5m x 38cm | 16 sq. ft / 1.5m2 | 88 lbs / 39.9 kg | 1000 lbs / 453.6kg |
| 2 | 40” Dock | 40 x 120 x 15” / 1m x 3m x 38cm | 32 sq. ft. / 3m2 | 167 lbs / 75.7 kg | 2000 lbs / 907.2 kg |
| 3 | 60” Dock | 60 x 120 x 15” / 1.5m x 3m x 38cm | 49 sq. ft | 257 lbs / 116.5 kg | 3000 lbs / 1360.8 kg |
| 4 | 80” Dock | 80 x 120 x 15” / 2m x 3m x 38cm | 64 sq. ft / 4.6m2 | 338 lbs / 153.3 kg | 4000 lbs / 1814.4 kg |
| 5 | 100” Dock | 100 x 80 x 15” / 2.3m x 2m x 38cm | 49 sq. ft / 4.6m2 | 287 lbs / 130.1 kg | 3100 lbs / 1406 kg |
| 6 | Half Hex Dock | 60 x 120 x 15” / 1.5m x 3m x 38cm | 49 sq. ft / 4.5m2 | 189 lbs / 85.7 kg | 2000 lbs / 907.2 kg |
| 7 | Corner Gusset | 34 x 34 x 47” / 86cm x 86cm x 119cm | 31 sq. ft / 2.8m2 | 22 lbs / 9.9 kg | 221 lbs / 10 kg |
